Tube amp with low impedance Headphones
post-6413659
Thread Starter
Post #1 of 27

Hordsak

New Head-Fier
Joined
Dec 27, 2009
Messages
40
Reaction score
10
Joined
Dec 27, 2009
Posts
40
Likes
10
Is it a bad idea to use a Tube Amp with low impedance headphones? I currently have a Glow Audio Amp one, and I'm looking at purchasing the Audio Technica ATH-AD700 phones, that I believe only have 38 ohm impedance or so.

     Share This Post
post-6413678
Post #2 of 27

dongringo

500+ Head-Fier
Joined
Nov 9, 2009
Messages
760
Reaction score
11
Joined
Nov 9, 2009
Posts
760
Likes
11
There are a few out there that are doable such as the Woo WA6 or Mapletree Ear+HD (which I ordered and am waiting for) that will drive most impedances. OTL amps aren't the way to go. Look for a transformer coupled amp or one that has a low output impedance. Either that or look for hybrids.

     Share This Post
post-6413697
Post #3 of 27

St3ve

100+ Head-Fier
Joined
Dec 21, 2009
Messages
346
Reaction score
14
Joined
Dec 21, 2009
Posts
346
Likes
14
Quote:

Originally Posted by dongringo /img/forum/go_quote.gif
There are a few out there that are doable such as the Woo WA6 or Mapletree Ear+HD (which I ordered and am waiting for) that will drive most impedances. OTL amps aren't the way to go. Look for a transformer coupled amp or one that has a low output impedance. Either that or look for hybrids.


X2 on the WA6 or MAD ear+. I started this thread about OTL tube amps and low impedance headphones, and the consensus was that transformer-couple jobs (like the WA6 and Ear+) are the safer option. That isn't to say that some OTLs don't work nicely - some people find they work just fine - but TC tube amps can technically pander to low impedance better. I have heard of some OTL amps which actually output low impedance aswell - the Zana Deux being one of them (unless my memory is faulty). FWIW I am using a WA6 with some low-impedance cans (RS1i) and they sound brilliant together.

     Share This Post
post-6414137
Post #4 of 27

Hordsak

New Head-Fier
Joined
Dec 27, 2009
Messages
40
Reaction score
10
Joined
Dec 27, 2009
Posts
40
Likes
10
I found these specs for my tube amp on their website. From this info, it seems I should be ok. What do you guys think though?

Amp One
SPECIFICATIONS
OUTPUT IMPEDANCE
Speakers: 4Ω~8Ω
Earphone: 32Ω~600Ω
OUTPUT POWER
5W×2 at 1KHz
Earphone: 600mW

     Share This Post
post-6414151
Post #5 of 27

freakydrew

500+ Head-Fier
Joined
Mar 21, 2009
Messages
656
Reaction score
10
Joined
Mar 21, 2009
Posts
656
Likes
10
The 700's will be fine amped or unamped, so I would go for it, sit back and enjoy...

and in case no one has mentioned it yet, sorry about your wallet

     Share This Post
post-6414205
Post #6 of 27

Hordsak

New Head-Fier
Joined
Dec 27, 2009
Messages
40
Reaction score
10
Joined
Dec 27, 2009
Posts
40
Likes
10
Oh, my wallet is already starting to feel the pain.. tube amps aren't cheap hehe.

     Share This Post
post-6414223
Post #7 of 27

K_19

Headphoneus Supremus
Joined
Sep 29, 2008
Messages
3,071
Reaction score
62
Joined
Sep 29, 2008
Posts
3,071
Likes
62
My transformer-coupled WA6 is fantastic with both low impedence and high impedence cans. Actually, they amp more of my low impedence stuff (RS1, K701, ESW10) than high impedence (HD650) currently.

     Share This Post
post-6414714
Post #8 of 27

ford2

Headphoneus Supremus
Joined
Apr 8, 2007
Messages
1,827
Reaction score
26
Joined
Apr 8, 2007
Posts
1,827
Likes
26
Quote:

Originally Posted by Hordsak /img/forum/go_quote.gif
Is it a bad idea to use a Tube Amp with low impedance headphones? I currently have a Glow Audio Amp one, and I'm looking at purchasing the Audio Technica ATH-AD700 phones, that I believe only have 38 ohm impedance or so.


The only problem with some amps with low impedance phones is noise,very much so if there sensitivity is up around 104 dB/mW.

     Share This Post
post-6415904
Post #9 of 27

VALIENTE

1000+ Head-Fier
Joined
Dec 1, 2008
Messages
1,004
Reaction score
26
Joined
Dec 1, 2008
Posts
1,004
Likes
26
Quote:

Originally Posted by dongringo /img/forum/go_quote.gif
Either that or look for hybrids.


Excuse me guys, are hybrid amps really good for low impedance headphones?
is WA6 a hybrid amp?

     Share This Post
post-6416127
Post #10 of 27

atbglenn

Headphoneus Supremus
Joined
Dec 9, 2006
Messages
1,661
Reaction score
23
Joined
Dec 9, 2006
Posts
1,661
Likes
23
Quote:

Originally Posted by VALIENTE /img/forum/go_quote.gif
Excuse me guys, are hybrid amps really good for low impedance headphones?
is WA6 a hybrid amp?



The Woo WA6 is not a hybrid. It's 100% tubes including the rectifier. It's an excellent choice for both high and low impedance loads because it uses an output transformer which has both high and low impedance outputs

From what I hear, hybrid amps excel at driving low impedance loads. I'm not sure how well they do with high impedance's

     Share This Post
post-6416131
Post #11 of 27

St3ve

100+ Head-Fier
Joined
Dec 21, 2009
Messages
346
Reaction score
14
Joined
Dec 21, 2009
Posts
346
Likes
14
Quote:

Originally Posted by VALIENTE /img/forum/go_quote.gif
Excuse me guys, are hybrid amps really good for low impedance headphones?
is WA6 a hybrid amp?



Yes, hybrid amps are considered a good match for low impedance headphones, as the solid state output stage can supply the amount of current favoured by low impedance designs. To clarify, a hybrid is a tube pre-stage with a solid stage output stage.

As for the WA6, it is not a hybrid amp, it is a pure tube design. Amps like WA6 make use of output transformers as a means of matching the output to either high or low impedances.

     Share This Post
post-6961507
Post #12 of 27

stratowhammy

Head-Fier
Joined
Apr 26, 2010
Messages
91
Reaction score
12
Joined
Apr 26, 2010
Posts
91
Likes
12
Yes, I have a pair of Shure SRH-840s which are powerhogs but only run at 44ohms.  I have a Little Dot I+ hybrid and I've never heard my cans sound better.  I would definitely recommend a hybrid, but I too was wondering if I should upgrade to something like the LD III tube amp for better imaging, sq, etc.

     Share This Post
post-6961556
Post #13 of 27

nikongod

DIY-ku
Joined
Jan 24, 2005
Messages
8,882
Reaction score
119
Joined
Jan 24, 2005
Posts
8,882
Likes
119

Quote:
Quote:

Originally Posted by Hordsak /img/forum/go_quote.gif
Is it a bad idea to use a Tube Amp with low impedance headphones? I currently have a Glow Audio Amp one, and I'm looking at purchasing the Audio Technica ATH-AD700 phones, that I believe only have 38 ohm impedance or so.


The only problem with some amps with low impedance phones is noise,very much so if there sensitivity is up around 104 dB/mW.

I disagree with this, well I disagree that it is implicating that tube amps are inherently noisier than other types of amps. This is definitely not the case. Any amp can be noisy.

db/mw is a bad way to look at whether a particular thing will be noisy. There are quite a few high impedance headphones pushing close to 100db/mw after all... you have to have an especially speshul amp for someone to say that they are noisy. (A high gain SS amp with high impedance feedback/input impedance setting resistors should do just fine). db/mv is a better standard if you want to look at noise.

     Share This Post
post-6965212
Post #14 of 27

Frihed89

1000+ Head-Fier
Joined
Jan 4, 2006
Messages
1,444
Reaction score
53
Location
Copenhagen, Denmark
Joined
Jan 4, 2006
Location
Copenhagen, Denmark
Posts
1,444
Likes
53


Quote:
There are a few out there that are doable such as the Woo WA6 or Mapletree Ear+HD (which I ordered and am waiting for) that will drive most impedances. OTL amps aren't the way to go. Look for a transformer coupled amp or one that has a low output impedance. Either that or look for hybrids.


That's what I learned, too.  However, my SinglePower MPX-3 Slam SE is doing a great job of driving my Audeze LCD-2s.

     Share This Post
post-6965533
Post #15 of 27

musicman59

Headphoneus Supremus
Joined
May 27, 2004
Messages
4,431
Reaction score
515
Location
Canton, MI
Joined
May 27, 2004
Location
Canton, MI
Posts
4,431
Likes
515
What i have learn is that impedance matching is very important. If you have a tube amp like a Woo with high impedance and low impidance outputs wil work fine. I have notice a big difference in sound when I connect my D7000 in the low inpedance output compared to the high impedance output jack. Out of the high impedance output they just not sound right.

     Share This Post
