The Sony TA-ZH1ES Hi-Res Headphone Amplifier
A Brand New


A Table of Contents

1. Design/ Philosophy Notes (Directly Below)​
2. Transcription of Technical Interview (Internal Link)​
3. General Impressions By This Author (Coming)​
4. General Impressions by Other Members (Coming)​
5. Event and Release Videos (Internal Link)​



 ​
Links To Related Thread

MDR-Z1R ​
| ​

An Introduction From The Ground ​

Hello all!  It’s thatonenoob here, A little while back, the Sony Singapore Team reached out to me, saying that they had a rather interesting proposition.  I figured that it was probably going to be something along the lines of a new product release, and was naturally quite curious.  A couple of calls and a few emails later, and I found myself booked for a flight to the 2016 IFA in Berlin.   As it is now slightly past 1:15 PM here in Berlin on September 1st, I’m finally able to discuss in an official capacity the immensely exciting new Sony Hi-Res lineup. I know there’s already been some “info” that has arrived beforehand from a Chinese (?) source, but by nature of things I won’t be commenting on that channel.  Rest assured though, everything you see here is official, so speculation begone!

Currently, the atmosphere here at the press conference is hectic and filled with a great deal of excitement, and in the coming hours I will be posting all my impressions, photos, and videos right here in this thread.  In short, I will be bringing the Sony experience directly to y’all Head-Fi’ers.  Stay tuned.  Also, if you have questions, just let me know below, and if it can't already be answered I will try my best to make sure they do.

ETA to Next Update

I'll be rolling in updates as we go along.  I will eventually be posting the bulk of the the photos and videos in the coming day, and will be updating the threads as soon as I can.  Also, if you have questions, just let me know below, and if it can't already be answered I will try my best to make sure they do.

USD Prices (Projected For Asia)​

WM1Z - 3199
WM1A - 1199
ZH1ES - 2199
Z1R - 2199
1000X - 399

Specifications

Model Name
TA-ZH1ES Hi-Res Audio Headphone Amplifier
Hi-Res Audio
Yes
Power Output(32Ω, 1kHz, 1% Distortion)
Balanced Connection: 1200mW + 1200mW
Unbalanced Connection: 300mW + 300mW
Output Impedance
8-600Ω
Frequency Characteristics
4-80,000Hz(-3dB)
Gain Switch
Yes (High/Low)
Headphone Jack
Balanced standard (4.4 mm in diameter), 3-pole mini (balanced connection, 3.5 mm in diameter) × 2, XLR4 (balanced 4-pin), Standard (6.3 mm in diameter), Stereo mini (3.5 mm in diameter)
Audio Inputs
Walkman®/Xperia input, USB-B input, Coaxial input, Optical input, Line Input
Supported Sampling Frequencies/Bit
PCM: Up to 768kHz /32bit
DSD: Up to 22.4 MHz
Sound Enhancements
DSEE HX™, DSD Remastering Engine, DC Phase Linearizer, LR Balance Adjust
Dimensions (WxHxD)
Approx. 210 x 65 x 314mm
Weight
Approx. 4,400g


Design/ Philosophy


Key Features
There's several key aspects of the DAP:
  1. DA Hybrid Amplifier Circuit w/ enhanced S-Master HX Technology
  2. Advanced signal processing technology through further development of DSEE HX and DSD Remastering Engine
  3. Vibration Reduced Chassis
  4. 4.4 mm Balanced Connection



     Share This Post
post-12830327
Post #2 of 3,829

thatonenoob

Reviewer: PMR Audio
Joined
Sep 15, 2014
Messages
2,395
Reaction score
1,985
Joined
Sep 15, 2014
Posts
2,395
Likes
1,985
Technical Interview

Our extremely interesting technical interview with the Sony Engineers.  It's got quite a bit of everything, and I've more or less kept track of the conversation via a numbered list of captions.  We had some issues with the translation, and I think I will elaborate more.  Some of the initial concern was that the press info was not as technical as some may have liked. We also didn't have a technical ready translator on hand (i.e. engineer trained etc.) Last, it was rapid fire style as we did not have all that much time. To me, it was still informative, and despite not being too smooth something I'd still like to share.

 ​

     Share This Post
post-12830376
Post #3 of 3,829

thatonenoob

Reviewer: PMR Audio
Joined
Sep 15, 2014
Messages
2,395
Reaction score
1,985
Joined
Sep 15, 2014
Posts
2,395
Likes
1,985
Member Impressions/ Reviews

Here I will try to compile impressions/ reviews from members as well as external sources.  Feel free to just drop me a PM if you would like to be linked to in this section.  I sometimes have difficulty keeping up with all the thread posts.  Thanks!

  1. Phileweb Review by
    Tadashi Yamanouchi​
     (in Japanese)
  2. Official Sony Japan Interview with Tsunoda, Inayama, and Sato (sorry, this is what I got from Gtranslate)

Event and Release Videos

The Official Sony Press Video for the TA-ZH1ES.​
 ​
 ​

     Share This Post
post-12830578
Post #4 of 3,829

cthomas

500+ Head-Fier
Joined
Feb 7, 2014
Messages
598
Reaction score
86
Joined
Feb 7, 2014
Posts
598
Likes
86
I think all those outputs are overkill. Would've been nice if it had somewhere to connect a pair if speakers too, like the uda-1 but with a lot more power.

     Share This Post
post-12830744
Post #5 of 3,829

deafdoorknob

1000+ Head-Fier
Joined
Jul 31, 2015
Messages
1,179
Reaction score
1,397
Location
2046
Joined
Jul 31, 2015
Location
2046
Posts
1,179
Likes
1,397
[VIDEO]https://m.youtube.com/watch?v=_PrU4uEw2GM&itct=CA8QpDAYAyITCPCz8J-g7s4CFREffwod_0kBNzIGcmVsbWZ1SL-jtamw1sCc9gE%3D
[/VIDEO]

publicity video with its chief engineer

     Share This Post
post-12831170
Post #6 of 3,829

NPWS

100+ Head-Fier
Joined
Dec 1, 2015
Messages
372
Reaction score
56
Joined
Dec 1, 2015
Posts
372
Likes
56
Website
www.instagram.com
it's supposed to be desktop amp, am I right? or transportable just like the size of bakoon amp HDA 5520

     Share This Post
post-12831278
Post #7 of 3,829

AxelCloris

Headphoneus Supremus
Administrator
Joined
Dec 19, 2011
Messages
7,339
Reaction score
2,855
Location
Motor City, USA
Joined
Dec 19, 2011
Location
Motor City, USA
Posts
7,339
Likes
2,855
I am very interested in this system and unfortunately it looks like all of the discussion is over the new DAPs and closed headphone. I've been looking for a system that uses the 4.4mm connector Sony announced at RMAF two years ago and it's finally here. Huzzah!
