Key Features
Digital Decoding
- Dual AK4499EQ, discontinued flagship 32-bit DAC chipset, mono mode, paralleled current outputs
- Decode PCM up to 32bit/768kHz, DSD up to 1 Bit/22.6MHz (DSD512)
- Ample 2x2 IV converter network to enhance DAC output
- Comprehensive digital output option: I2S (mini HDMI), USB Audio (USB-C), and S/PDIF Coaxial (Embedded USB-C)
- Balanced tube amplification with matched paired KORG Nutube 6P1
- Fully-discrete fully-balanced NPN/PNP Push-pull headphone amplifier supports dedicated 3.5mm single-ended and 4.4mm balanced phone output
- Triple Timber (Nutube Classic, Nutube Modern, Solid-state) from Gen3 vacuum tube audio circuit
- Dual Amplifier Mode (Choice of Class A/Class AB)
- Dual Output Mode: P (Standard) and P+ (High Power) mode
- Hyper Mode: Combing Class A, P+, and numerous operation adjustments to deliver ultimate performance
- Highly linear volume control through a pair of low noise, low distortion resistance ladder-based MUSES72320 stereo electronic volume
- Desktop grade 3.5mm single-ended (2.1V, 1.6V, 1.0V) and 4.4mm balanced (4.2V, 3.2V, 2.0V) selectable output level Line Out
- 3.5mm single-ended and 4.4mm balanced Preamp output
- 470mF/5.5V ELDC (Electric Double-Layer Capacitor) ultra-capacitor as power reserve in the main power supply system.
- Compartmented CNC Aluminum frame to improve heat dispersion, reduce internal interference and minimize vacuum tube microphonic
- CNC machines TC21 Titanium alloy steel chassis for lightweight and robustness
- Snapdragon 665 CPU with 8G DDR4 RAM running customized Android 12 with Google Player preinstalled
- Storage capacity: 256 GB internal memory, one microSD card up to 512 GB
- DTA bypasses Android SRC, Hi-Res playback, and streaming to all applications
- Multi-color smart glowing sampling rate indicator integrated below the gold-plated brass Volume control knob.
- 6.0” 1080x2160 FHD+ Incell screen support double tap to wake and gestures
- 12570mAh (3.8V, 48Wh) high-capacity polymer lithium-ion battery, support PD2.0 fast charging technology
- 156mm x 89mm x 25mm, ~650g
Upgrades to the N30LE Standard Version
- Upgraded Crystal Oscillator to the Class Leading CCHD-575.
- Upgraded the FET Tubes to the Legendary Original Toshiba 2SK389.
- Upgraded the Timbre Circuit JEFT to TI JFE150.
- Special Back Panel and Accessories.
- Cayin x Unique Melody Amber Pearl IEMs-- 4 Bass + 2 Mid + 2 Upper Mid + 4 Treble + 2 Electrostatics Ultra-High + 1 the Newest Full-range FreqShift Bone Conduction. Multipoint Configuration with 6-way Crossover. Stabilized Cholla Shells.
