The world’s most advanced Table Top DAC, preamp and headphone amp just got better. In every way! Hello, Hugo TT 2.



Hugo TT 2 has been radically redesigned from the ground up, not only with beautiful new casework by Chief Designer, John Franks, but with 5x the processing power of the original Hugo TT and double that of the multi-award-winning Hugo 2. Hugo TT 2 distils over 20 years of digital development by Rob Watts and takes advantage of the very latest technology.

As expected, it delivers radically improved technical specifications and measurements across the board and exhibits drastic sonic benefits over its predecessor with 768kHz PCM and DSD 512 playback. Hugo TT 2 sets a new benchmark in table top audio, only being eclipsed by DAVE.

Delving deeper, in comparison to the 256-tap filters that traditional chip DACs may run at, Hugo TT 2’s beating heart is an infinitely more powerful Xilinx Artix 7 FPGA, custom-coded by Chord Electronics’ Rob Watts, with 86x 208MHz cores running in parallel to create an advanced 16FS WTA 1 filter with 98,304-taps. Double that of its multi-award winning transportable brother, Hugo 2 (49,152). Hugo TT 2 also benefits from an upgrade from a 4-element design to a 10-element design, which works in harmony with the radically upgraded FPGA and code to deliver unrivalled audio.


A brand new high-power discreet output stage coupled with second-order noise-shaping integrated between the DAC output and filter is also employed to massively reduce distortion. Further improvements have also been made to the power delivery. Hugo TT 2 eschews the Li-Po battery power supply of the original and ushers in six super capacitors capable of delivering huge, linear dynamic currents when the music demands it with peak output of 5A, 9.3V RMS.


Hugo TT 2 also brings home the much loved four-stage user-selectable filter controls introduced with Hugo 2 and retains the three-stage user-selectable digital crossfeed function for headphone users who want to improve the perception of depth, similar to that of speakers.

AVAILABLE: AUTUMN 2018

UK RRP: £3,996.00

LEARN MORE: http://chordelectronics.co.uk/product/hugott2/



Last edited:
Chord Electronics Stay updated on Chord Electronics at their sponsor page on Head-Fi.

https://www.facebook.com/chordelectronics https://twitter.com/chordaudio http://www.chordelectronics.co.uk/
post-14231118
Post #3 of 9,863

514077

Headphoneus Supremus
Joined
Mar 9, 2013
Messages
3,711
Reaction score
1,556
Joined
Mar 9, 2013
Posts
3,711
Likes
1,556
E3,9XX. Betting about $4,800 Canadian. About $4,200 U.S. Maybe worse for Canada as usual.
On another note; there goes the possibility of a slimmed-down M-Scaler, as that might cut into TT2 sales. But, who knows?

     Share This Post
post-14231127
Post #5 of 9,863

AndrewH13

Headphoneus Supremus
CanJam London 2017 Ping Pong Champion
Joined
Sep 8, 2013
Messages
2,279
Reaction score
1,352
Location
Southend, England
Joined
Sep 8, 2013
Location
Southend, England
Posts
2,279
Likes
1,352
Shows £3996 in post 1 above!

Must admit when I demoed and reviewed the TT1 in Chord’s UK tour, it made a lasting impression. To me there was a bigger jump up from my Hugo 1 than I got from Hugo 2, in muscle if not detail. I bought Hugo 2 and love it, due to that being at the top end of my price range. But if this improves on TT1, then it will have killer sound :)

     Share This Post
post-14231156
Post #7 of 9,863

514077

Headphoneus Supremus
Joined
Mar 9, 2013
Messages
3,711
Reaction score
1,556
Joined
Mar 9, 2013
Posts
3,711
Likes
1,556
Shows £3996 in post 1 above!

Must admit when I demoed and reviewed the TT1 in Chord’s UK tour, it made a lasting impression. To me there was a bigger jump up from my Hugo 1 than I got from Hugo 2, in muscle if not detail. I bought Hugo 2 and love it, due to that being at the top end of my price range. But if this improves on TT1, then it will have killer sound :)
Sound like it'll be a bigger step-up from Hugo2 than tt1 was from H1. I never felt the desire to buy a TT, as the same DAC techno was unchanged. But this! Oh, I must at least hear one sometime. Congrats to Chord for uping the game.

     Share This Post
  • Like
Reactions: GreenBow
post-14231168
Post #8 of 9,863

JaZZ

Headphoneus Supremus
Joined
May 9, 2002
Messages
9,633
Reaction score
1,590
Location
Zürich, Switzerland
Joined
May 9, 2002
Location
Zürich, Switzerland
Posts
9,633
Likes
1,590
Age
70
Output power (unbalanced): (@1% THD) 288 mW RMS 300Ω; 7.3 W RMS 8Ω

In other words: ideal for driving speakers.

post-14231193
Post #9 of 9,863

maxh22

1000+ Head-Fier
Joined
Apr 18, 2016
Messages
1,333
Reaction score
424
Joined
Apr 18, 2016
Posts
1,333
Likes
424
Shows £3996 in post 1 above!

Must admit when I demoed and reviewed the TT1 in Chord’s UK tour, it made a lasting impression. To me there was a bigger jump up from my Hugo 1 than I got from Hugo 2, in muscle if not detail. I bought Hugo 2 and love it, due to that being at the top end of my price range. But if this improves on TT1, then it will have killer sound :)
If it cost $6K it would make more sense to get a used Dave for around $7-8K

Output power (unbalanced): (@1% THD) 288 mW RMS 300Ω; 7.3 W RMS 8Ω

In other words: ideal for driving speakers.
But on the other hand, that power output is a huge improvement over any of Rob's previous designs!

I wonder if it is the same for the headphone jacks?

Last edited:
post-14231208
Post #10 of 9,863

514077

Headphoneus Supremus
Joined
Mar 9, 2013
Messages
3,711
Reaction score
1,556
Joined
Mar 9, 2013
Posts
3,711
Likes
1,556
Output power (unbalanced): (@1% THD) 288 mW RMS 300Ω; 7.3 W RMS 8Ω

In other words: ideal for driving speakers.
Or giving a kick to Audeze or other planars, if needed of course.

     Share This Post
  • Like
Reactions: JaZZ
post-14231211
Post #11 of 9,863

JaZZ

Headphoneus Supremus
Joined
May 9, 2002
Messages
9,633
Reaction score
1,590
Location
Zürich, Switzerland
Joined
May 9, 2002
Location
Zürich, Switzerland
Posts
9,633
Likes
1,590
Age
70
Yeah, that's what I thought, too – it will definitely drive any headphone on the planet... Susvara, LCD4 & Co.

     Share This Post
  • Like
Reactions: maxh22 and 514077
post-14231238
Post #12 of 9,863

austinpop

100+ Head-Fier
Joined
Jul 19, 2004
Messages
376
Reaction score
149
Joined
Jul 19, 2004
Posts
376
Likes
149
Very exciting announcement! Key features for me are:
  1. Prodigious output power for driving speakers
  2. Big boy connectors - no dinky USB-C
  3. No battery
  4. Balanced outputs
  5. External power input, so could use a really high quality DC supply like a Paul Hynes
  6. Finally, perfect precursor to the Mscaler, since has dual BNC inputs, and with its beefy analog stage, would be the perfect back end for the Mscaler.
Questions for @ChordElectronics and/or @Rob Watts :
  1. What is the minimum spec for the DC power supply, if replacing the supplied SMPS? In terms of voltage range, ave and peak amps, or even recommended transformer size (VA). I am thinking this would benefit from a massive PH SR-7 which has a 250VA core, and can deliver 10A sustained. Just wondering if something even bigger would help. After all, in the "driving speakers" use case, this is functioning as a DAC and amp.
  2. Description says supplied SMPS is 12V, but the picture of the back panel says 15V in.
  3. What is the maximum DSD input rate over DoP?
  4. Are the analog output circuits truly balanced?

     Share This Post
  • Like
Reactions: musickid
post-14231244
Post #13 of 9,863

Whazzzup

Headphoneus Supremus
Joined
Jan 26, 2014
Messages
6,813
Reaction score
4,942
Location
Toronto, Canada
Joined
Jan 26, 2014
Location
Toronto, Canada
Posts
6,813
Likes
4,942
OK so is this the official TT2 thread or the TT2 launched today thread?

     Share This Post
post-14231245
Post #14 of 9,863

Whazzzup

Headphoneus Supremus
Joined
Jan 26, 2014
Messages
6,813
Reaction score
4,942
Location
Toronto, Canada
Joined
Jan 26, 2014
Location
Toronto, Canada
Posts
6,813
Likes
4,942
there is a battery, updated super capacitors

     Share This Post
