Android phones and USB DACs
post-8132621
Thread Starter
Post #1 of 9,399

NZtechfreak

Headphoneus Supremus
Joined
Jan 19, 2012
Messages
3,230
Reaction score
603
Joined
Jan 19, 2012
Posts
3,230
Likes
603
Wow, it was three years ago I started this post on Head-Fi about USB audio on Android...

I thought I would update the first post today to point to the post that contains all of the most up to date resources for this topic, from the fantastic and dedicated DanBa here. EDIT: Updated to DanBa's newest information on 27 Nov 2015.

The information from that post is here, but no doubt will be superceded by updates from DanBa in due course:

Android USB audio

Information search:
1. Click on the following link
https://www.google.fr/?gws_rd=ssl#q=%22XY%22+site:http:%2F%2Fwww.head-fi.org%2Ft%2F595071%2Fandroid-phones-and-usb-dacs
2. Replace XY by your search keyword(s).

FAQ:
http://goo.gl/A4dCnP

A list of USB OTG cables / adapters:
http://goo.gl/4JyOe5

A list of USB Type-C cables / adapters:
https://goo.gl/n1cxPx

A list of stock Android-powered devices reportedly interworking with compatible USB DAC:
stock Android device > digital USB audio out >> USB DAC >> amp >> headphones
http://goo.gl/ksoF0d

A list of USB Audio Player PRO resources (compatible USB DAC, compatible Android devices, ...):
http://www.extreamsd.com/USBAudioRecorderPRO/

A list of standard USB DAC reportedly interworking with the Android-powered smartphone Samsung Galaxy S3 having a microSD card slot:
stock Samsung Galaxy S3 > digital USB audio out >> USB OTG cable (ID pin grounded) >> USB DAC >> amp >>headphones
http://goo.gl/yBKivk

A list of standard USB DAC reportedly interworking with the Android-powered smartphone Samsung Galaxy Note2 having a microSD card slot:
stock Galaxy Note2 > digital USB audio out >> USB OTG cable (ID pin grounded) >> USB DAC >> amp >>headphones
http://goo.gl/Ga1jYw

A list of standard USB DAC reportedly interworking with the Android-powered smartphone Samung Galaxy S4 having a microSD card slot:
stock Samsung Galaxy S4 > digital USB audio out >> USB OTG cable (ID pin grounded) >> USB DAC >> amp >>headphones
http://goo.gl/dIwrqp

A list of standard USB DAC reportedly interworking with the Android-powered smartphone Samsung Galaxy Note3 having a microSD card slot:
stock Samsung Galaxy Note3 > digital USB audio out >> USB OTG cable (ID pin grounded) >> USB DAC >> amp >> headphones
http://goo.gl/7Bvkhz

A list of standard USB DAC reportedly interworking with the Android-powered smartphone Samung Galaxy S5 having a microSD card slot:
stock Samsung Galaxy S5 > digital USB audio out >> USB OTG cable (ID pin grounded) >> USB DAC >> amp >>headphones
http://goo.gl/zUjud0

A list of standard USB DAC reportedly interworking with the Android-powered smartphone Samsung Galaxy Note4 having a microSD card slot:
stock Samsung Galaxy Note4 > digital USB audio out >> USB OTG cable (ID pin grounded) >> USB DAC >> amp >> headphones
http://goo.gl/gnmvuf

USB DAC descriptors:
http://goo.gl/pYJbTu

The basics:
http://goo.gl/MCFY2x

post-8132662
Post #2 of 9,399

scohen158

Head-Fier
Joined
Jan 18, 2012
Messages
99
Reaction score
12
Joined
Jan 18, 2012
Posts
99
Likes
12
Voted for it as I want my Samsung Galaxy S II to have this when it gets ICS.

     Share This Post
  • Like
Reactions: NZtechfreak
post-8133650
Post #3 of 9,399

NZtechfreak

Headphoneus Supremus
Joined
Jan 19, 2012
Messages
3,230
Reaction score
603
Joined
Jan 19, 2012
Posts
3,230
Likes
603


Quote:
Voted for it as I want my Samsung Galaxy S II to have this when it gets ICS.


Many thanks, seems like there are a few Android users here, so hopefully we can get this issue up the ladder!

Incidentally, 56 new votes today, issue up 12 places.

     Share This Post
post-8134106
Post #4 of 9,399

iahtoyhz

New Head-Fier
Joined
Feb 10, 2012
Messages
1
Reaction score
10
Joined
Feb 10, 2012
Posts
1
Likes
10
I would LOVE to have the flexibility of choosing a new Android smartphone or tablet and being able to send USB out to one of the many, many portable DAC/AMP combos that are on the market.

Not knowing (personally) how Google prioritizes things, how likely is this to happen?

     Share This Post
post-8139347
Post #5 of 9,399

DanBa

Headphoneus Supremus
Joined
Nov 12, 2009
Messages
1,721
Reaction score
262
Joined
Nov 12, 2009
Posts
1,721
Likes
262
@Nztechfreak

Thanks!

     Share This Post
post-8139370
Post #6 of 9,399

DanBa

Headphoneus Supremus
Joined
Nov 12, 2009
Messages
1,721
Reaction score
262
Joined
Nov 12, 2009
Posts
1,721
Likes
262


Quote:
I would LOVE to have the flexibility of choosing a new Android smartphone or tablet and being able to send USB out to one of the many, many portable DAC/AMP combos that are on the market.

Not knowing (personally) how Google prioritizes things, how likely is this to happen?

It will happen.

According to Android specifications, USB audio is included in Android 3.1 or newer platforms.
http://developer.android.com/guide/topics/usb/index.html
http://developer.android.com/reference/android/hardware/usb/UsbConstants.html

It is up to Google for its reference Nexus devices and the other Android device manufacturers to support or enable the USB audio feature on their devices.

Example: The Android 3.2 powered Archos G9 tablet interworks with a USB DAC/amp FiiO E17
http://www.jbmm.fr/2012/01/utiliser-le-dac-fiio-e17-avec-son-archos/ http://www.archos.com/products/gen9/archos_101g9/index.html?country=us&lang=en http://update.archos.com/9/gen9/changes_firmware_archos_android_gen9.htm





Version 3.2.22 - September 2nd, 2011: no USB audio support!
Initial Honeycomb 3.2 firmware release

Version 3.2.77 - December 6th, 2011
Accessories: external USB audio cards (DAC) support has been added

Version 3.2.78 - December 19th, 2011
Audio accessory: fix USB DAC not supporting 44.1kHz


We should put pressure on Google, and therefore on the Android device manufacturers.


     Share This Post
post-8142160
Post #8 of 9,399

Sorensiim

Headphoneus Supremus
Joined
Dec 11, 2008
Messages
4,264
Reaction score
911
Joined
Dec 11, 2008
Posts
4,264
Likes
911
Starred


My Nexus S is running ICS and my Galaxy Tab 10.1 will get the upgrade soon enough.

     Share This Post
post-8144034
Post #10 of 9,399

Mauricio

500+ Head-Fier
Joined
Feb 4, 2012
Messages
634
Reaction score
28
Joined
Feb 4, 2012
Posts
634
Likes
28
Forget USB, and lose the cable.  What we should be advocating, and what I am waiting for is for wireless streaming from an Android device to a DAC via Bluetooth or Wifi.  As I understand it, the AptX codec needs to be supported by the DAC and the streming device.  That's the way to go, rather than tethering via USB.

     Share This Post
post-8144380
Post #11 of 9,399

emonkey

New Head-Fier
Joined
Nov 24, 2011
Messages
30
Reaction score
12
Joined
Nov 24, 2011
Posts
30
Likes
12
Commented the developer thread!  This feature may be the last nail in the coffin to move from my antiquated nokias to android ICS


     Share This Post
post-8150848
Post #12 of 9,399

Wouter

New Head-Fier
Joined
Aug 17, 2011
Messages
17
Reaction score
11
Joined
Aug 17, 2011
Posts
17
Likes
11
Voted as the standard sound quality of my HTC Desire S is quite poor.
The suggested wireless alternative is indeed a better solution, however are there any wireless portable DAC/AMPS available?
Since there are many portable USB DAC/AMP's available alread, I'd prefer that Google enables "usbaudio" first.
In fact I consider it quite surprising Google didn't do so earlier, particularly as this feature has been available for a long time already on IOS devices.


     Share This Post
  • Like
Reactions: scrypt
post-8150882
Post #13 of 9,399

InfectedStyles

New Head-Fier
Joined
Sep 13, 2011
Messages
28
Reaction score
10
Joined
Sep 13, 2011
Posts
28
Likes
10
Starred this. Please everyone vote this up. Only a few stars are needed to move this up a couple more places.

     Share This Post
post-8151327
Post #14 of 9,399

kenman345

Headphoneus Supremus
Joined
Nov 22, 2011
Messages
2,891
Reaction score
86
Joined
Nov 22, 2011
Posts
2,891
Likes
86
Their is a USB driver that is in Ice Cream Sandwich that is meant for connecting USB items to your phone.

     Share This Post
post-8153782
Post #15 of 9,399

dmcs414

100+ Head-Fier
Joined
Sep 5, 2007
Messages
424
Reaction score
11
Location
Houston, TX
Joined
Sep 5, 2007
Location
Houston, TX
Posts
424
Likes
11
I couldn't agree more. I have been looking at replacing my heavy 17" laptop with something akin to the Asus transformer tablet, but have been unsure whether I'd regret losing the ability to use foobar, USB 3.0, etc and a multitude of great USB DAC functionality I currently enjoy. It would also be nice to be able to use my Moto Photon 4G phone in the same way, but Motorola is always behind though on what version of Android they accept, so fat chance of that ever coming to fruition.

Also your avatar is adorable and makes me grab one of my cats for some lap time every time I see it. Kittens FTW. :p


It will happen.

According to Android specifications, USB audio is included in Android 3.1 or newer platforms.
http://developer.android.com/guide/topics/usb/index.html
http://developer.android.com/reference/android/hardware/usb/UsbConstants.html

It is up to Google for its reference Nexus devices and the other Android device manufacturers to support or enable the USB audio feature on their devices.

Example: The Android 3.2 powered Archos G9 tablet interworks with a USB DAC/amp FiiO E17
http://www.jbmm.fr/2012/01/utiliser-le-dac-fiio-e17-avec-son-archos/ http://www.archos.com/products/gen9/archos_101g9/index.html?country=us&lang=en http://update.archos.com/9/gen9/changes_firmware_archos_android_gen9.htm





Version 3.2.22 - September 2nd, 2011: no USB audio support!
Initial Honeycomb 3.2 firmware release

Version 3.2.77 - December 6th, 2011
Accessories: external USB audio cards (DAC) support has been added

Version 3.2.78 - December 19th, 2011
Audio accessory: fix USB DAC not supporting 44.1kHz


We should put pressure on Google, and therefore on the Android device manufacturers.


     Share This Post
  • Like
Reactions: prax
