Model: Monitor 02 US mark2
Product Category: Sound Card -> Monitor
Specifications: Digital Playback up to 32Bit / 384KHz, optional external power supply sound card. Support DSD hardware playback. Can directly drive the impedance of 300 ohm headphone, coaxial, optical fiber, MULINK output.
● Product Introduction
Monitor, condensed music state for many years the essence of technology and audio research. Power UP powered technology makes a small metal body to make a significant driving force. Direct play hardware DSD audio stream, while continuing the classic at the same time, to provide users with more fidelity, better sound. Line, headphone output free to switch; digital knob volume control, filling the people-oriented design concept. Optional external power supply or battery-powered, line, 6.3MM , 3.5MM headphone independent interface, optical fiber, coaxial, MULINK output, ASIO playback, DTS and Dolby source output, DSD audio signal decoding ......, omnipotent application environment , 120dB rich taste of music output, domineering exposed, give me who?
• Advanced chipset architecture
MUSILAND Audio Labs latest SuperDSP210 high-definition audio chipset that supports true USB2.0 high-speed transmission, instantaneous transfer rate up to 480Mbps . With MUSILAND 's dedicated driver, the original DSD data can be transferred to the chipset via a high-speed bus for processing. Cache and multi-state machine processing mechanism, making USB high-speed transfer of data to achieve real-time.
SuperDSP210 HD audio chipset supports true 32Bit audio data processing, sampling rate up to 384KHz . With the audio clock generated by the DCM (clock management module) inside the SuperDSP 210 , the sound file is restored and the harmonic distortion is close to the human hearing threshold. The precision S / PDIF transmitter realized by independent FPGA , can finish the popular digital signal output such as PCM , Dolby Digital , DTS . Because this S / PDIF transmitter is driven by a precision clock, the output signal jitter is very low, exactly what the audio lab requires for test equipment. The next generation of MULINK interface, 32Bit HD audio data and DSD data source can be output to an external decoder or other digital audio.
• Practical functional interface
Monitor 02 US mark2 sound card with high-quality stereo line output, headphone output, optical output, RCA coaxial output, MULINK high-definition audio output interface.
Monitor 02 US mark2 sound card with lines, headphone output free to switch, digital knob volume control, filling the people-oriented design concept.
Sound card comes with 2 sets of headphone output interface, suitable for connecting a variety of interfaces and sensitivity headphones or earplugs, for a variety of audio files to enjoy.
Monitor 02 US mark2 sound card with high quality digital fiber, RCA coaxial output interface, capable of outputting pure stereo PCM encoded signal and multi-channel format Dolby Digital ( AC-3 ), DTS digital signal, by connecting external Advanced audio decoder, get better music appreciation; also can connect the decoding AV audio and video system , enjoy watching DVD blockbuster surround sound, enjoy the unprecedented cinema effect. You can also connect MD devices for digital music transcription.
Monitor 02 US mark2 sound card MULINK HD audio output interface, MUSILAND decoder can be connected to deliver jitter-free HD audio format, the audio quality far exceeds the traditional S / PDIF interface.
Monitor 02 US mark2 sound card using the latest power processing technology and headphone amplification technology, the use of USB self-powered, you can provide excellent sound quality and strong headphone driving force. Desktop or laptop for different chipsets.
• High-quality audio features
Monitor 02 US mark2 sound card up to 32Bit / 384KHz format audio processing, and uses up to 120dB SNR and dynamic range of digital-analog conversion chip, providing high-fidelity audio quality analog output.
Due to the use of the latest technology POWER-UP high-precision power supply, and multi-stage filter circuit processing, the USB interface voltage boost first, and then clean, to ensure that the computer USB interface, can also provide pure power supply features, Select external power supply or battery-powered.
The state-of-the-art balanced analog filter amplifier circuit provides the best balance of high resolution and musicality, while preserving the audio detail while maximizing the audible immunity of the sound.
2 sets of high efficiency headphone jack, with high output swing and high current output characteristics, can be more flexible to drive a variety of different impedance and sensitivity of the headset.
Monitor 02 US mark2 The digital output of the sound card adopts the asynchronous FIFO mode to output the digital signal. In this mode, the precise clock on the board will be used with the DCM of the SuperDSP210 to re- arrange the digital signal timing to reduce the jitter unique to the S / PDIF format. The maximum limit Enhances the quality of digital signal transmission.
Monitor 02 US mark2 sound card MULINK HD audio output interface, the FPGA of DCM manage real-time clock, with the change of the sampling rate, the clock synchronized with the output data to the decoder, in this way, the clock and data without complex Synchronization also eliminates the need for clock recovery operations. So basically no jitter transmission, HD audio details can be transmitted without loss. In addition, up to 32Bit of data is also S / PDIF specifications can not be achieved.
Monitor 02 US mark2 sound card also supports ASIO , providing ultra-low audio delay.
• Flexible software support
The Monitor 02 US mark2 sound card offers the perfect ASIO , WDM support and mainstream operating systems such as Windows XP , Windows Vista , Windows 7 , Windows 8, etc. by installing a proprietary driver developed by Music State .
Monitor 02 US mark2 sound card supports Universal USB Audio Class 2.0 , in the latest MAC , LINUX can be plug and play, and supports DSD hardware playback. The Monitor 02 US mark2 sound card is also perfectly supported for IOS or Android devices with integrated USB Audio Class 2.0 drivers .
You can also optimize the updated driver by the state after the music, making Monitor02 US mark2 sound card to play better audio performance.
● Typical parameters
• Analog output
Dynamic range ( D / A ): 120dB
Signal to noise ratio ( D / A ): 120dB
Total harmonic distortion ( D / A ): 0.005%
Frequency response ( 20Hz ~ 20KHz ): + -0.1dB
Output level: 2V rms
Output impedance: 10K Ω
Headphone jack 1 Output power: 120mW / RL = 300 [Omega]; 180mW / RL = 100 [Omega]
Headphone jack 2 output power: 260mW / RL = 32 Ω
• Digital Output
Dynamic range: 140dB
Signal to noise ratio ( A weighted): 140dB
Total Harmonic Distortion: 0.0001%
Frequency response ( 20Hz ~ 20KHz ): + -0dB
• Other
Input Interface: USB2.0 , voltage greater than 4.5V , current greater than 500mA, external supply voltage 5V.
Power consumption: ≤ 2.5W
Product color: black
Shell material: aluminum
Dimensions (shell): 98x86x25 ( mm )
Weight: 208 g
● Interface
1 pair RCA line output interface (stereo)
1 Ge 3.5mm headphone output interface
1 Ge 6.25mm headphone output interface
. 1 th 12mm MULINK output interface
1 square fiber digital output interface
. 1 th RCA digital coaxial connector
. 1 th B -type USB input interface
1 external power supply or battery-powered interface
● main features
Stereo analog output
USB2.0 high-speed transmission
24bit / 192kHz analog output
24bit / 192kHz coaxial / optical digital output
32bit / 384kHz MULINK digital output
Digital output PCM / Dolby Digital / DTS format
Support ASIO
Support MUSILAND MMDI interface
Output sampling rate manually set
Headphone, line output control panel to switch manually
Support digital knob volume control
Support 1Bit DSD audio signal hardware decoding playback
Driver supports Windows XP / VISTA / 7/8 system
Support for MAC , IOS , Linux , Android, etc. Almost all common operating systems that support USB Audio Class
● product accessories
The main card 1 sound card
USB2.0 data line
A warranty card
A quick installation guide
Special statement :
The state of music does not assume responsibility for any errors or omissions that may appear in this information.
· Product pictures for reference only, please prevail in kind sales.
· In order to continuously improve the performance of the product, the company reserves the right to change the characteristics, specifications and design of the product, the details of the changes without prior notice.
