Hi Jason. I've listened to one of the Jotunheim R preproduction units, and I have one question: can you make a more powerful version? Maybe something equivalent to two vidars in monoblock mode?
I'm asking because just as I got to an enjoyable volume level, the unit I was listening to started clipping.. So a Jotunheim R with more power will offer more peace of mind, at least for me that is.
This was what I was listening to when the clipping hapened by the way. Lots of electronica and bass.
Odd, because I've never had any problem getting to ear-bleeding levels on Jotunheim R with the SR1a, definitely above a Vidar into the resistor box.

With respect to a more powerful box, anything's possible--for several times the price, and in a much larger physical size. There are currently no plans for this.

Schiit Audio Stay updated on Schiit Audio at their sponsor page on Head-Fi.

https://www.facebook.com/Schiit/ http://www.schiit.com/
     Share This Post
post-15433606
Post #56,147 of 60,094

Tim van der Leeuw

100+ Head-Fier
Joined
Jun 24, 2019
Messages
179
Reaction score
272
Location
Diemen
Joined
Jun 24, 2019
Location
Diemen
Posts
179
Likes
272
Use an aquarium as music storage? Nice plan.

And finally I found the ultimate Snake Oil company website.
See for yourself all those beautiful products you can't do without.
Wear aluminum thongs to protect the nuts to be sure.
https://telos-audio.com.tw/
Not sure they fully understand their target-audience if they've got this product showing on a background-picture on their website...


     Share This Post
post-15433643
Post #56,148 of 60,094

tincanear

100+ Head-Fier
Joined
Sep 2, 2019
Messages
438
Reaction score
723
Location
west coast, USA
Joined
Sep 2, 2019
Location
west coast, USA
Posts
438
Likes
723
Gungnir MB-->SYS-->Aegir is my recommendation.
@Brubaca if you had stated that the sys was being used with volume maxxed out (just as a switch box, instead of being used to control the volume), then that changes my recommendation to that @sam6550a just listed. Interconnects should be of the low capacitance type, and kept short (1m max) especially between the Sys output and Aegir input.

Last edited:
     Share This Post
post-15433644
Post #56,149 of 60,094

W S L

New Head-Fier
Joined
May 5, 2019
Messages
16
Reaction score
15
Location
Singapore
Joined
May 5, 2019
Location
Singapore
Posts
16
Likes
15
Odd, because I've never had any problem getting to ear-bleeding levels on Jotunheim R with the SR1a, definitely above a Vidar into the resistor box.

With respect to a more powerful box, anything's possible--for several times the price, and in a much larger physical size. There are currently no plans for this.
Ok, i just talked to my dealer, and apparently i got the baffle compensation switch in the wrong position, because i followed what was written in the online instructions manual. Will try again later.

     Share This Post
post-15433657
Post #56,150 of 60,094

Roy G. Biv

100+ Head-Fier
Joined
Sep 30, 2017
Messages
303
Reaction score
1,175
Location
Fort Worth, TX
Joined
Sep 30, 2017
Location
Fort Worth, TX
Posts
303
Likes
1,175
Not sure they fully understand their target-audience if they've got this product showing on a background-picture on their website...
Anybody that knows anything about "Quantum Resonation Conditioning" knows that it can lift even the lowliest of earbuds to stratospheric levels. Sheesh....

post-15433661
Post #56,151 of 60,094

earnmyturns

Headphoneus Supremus
Joined
Aug 1, 2015
Messages
1,845
Reaction score
2,700
Location
SF Bay Area
Joined
Aug 1, 2015
Location
SF Bay Area
Posts
1,845
Likes
2,700
post-15433726
Post #56,153 of 60,094

Pietro Cozzi Tinin

Headphoneus Supremus
Joined
Jan 26, 2017
Messages
3,440
Reaction score
7,300
Location
Delft, The Netherlands
Joined
Jan 26, 2017
Location
Delft, The Netherlands
Posts
3,440
Likes
7,300
Age
56
Anybody that knows anything about "Quantum Resonation Conditioning" knows that it can lift even the lowliest of earbuds to stratospheric levels. Sheesh....
Oh not only cheap earbuds. Just ask Constanza.

     Share This Post
  • Like
Reactions: US Blues
post-15433744
Post #56,154 of 60,094

Brubacca

100+ Head-Fier
Joined
Jun 5, 2014
Messages
401
Reaction score
523
Joined
Jun 5, 2014
Posts
401
Likes
523
@Brubaca if you had stated that the sys was being used with volume maxxed out (just as a switch box, instead of being used to control the volume), then that changes my recommendation to that @sam6550a just listed.
I'm sorry, I can be a bit thick.

If I go Gumby, SYS , Aegir then I would be using the volume pot in the sys. Still recommend this?

The Naim UnitiQute is an integrated amp with IC Chip volume control. Right now I only use Sys as switch box.

     Share This Post
post-15433746
Post #56,155 of 60,094

Roy G. Biv

100+ Head-Fier
Joined
Sep 30, 2017
Messages
303
Reaction score
1,175
Location
Fort Worth, TX
Joined
Sep 30, 2017
Location
Fort Worth, TX
Posts
303
Likes
1,175
post-15433751
Post #56,156 of 60,094

sam6550a

500+ Head-Fier
Joined
May 23, 2016
Messages
773
Reaction score
1,276
Location
Rural South Georgia
Joined
May 23, 2016
Location
Rural South Georgia
Posts
773
Likes
1,276
I'm sorry, I can be a bit thick.

If I go Gumby, SYS , Aegir then I would be using the volume pot in the sys. Still recommend this?

The Naim UnitiQute is an integrated amp with IC Chip volume control. Right now I only use Sys as switch box.
The SYS is totally passive. If the SYS volume control is at about 10 o'cloock or greater, you should not experience any sound quality loss, since Gumby has a low [75 ohm] output impedance.

     Share This Post
  • Like
Reactions: Rensek
post-15433790
Post #56,157 of 60,094

tincanear

100+ Head-Fier
Joined
Sep 2, 2019
Messages
438
Reaction score
723
Location
west coast, USA
Joined
Sep 2, 2019
Location
west coast, USA
Posts
438
Likes
723
I'm sorry, I can be a bit thick.

If I go Gumby, SYS , Aegir then I would be using the volume pot in the sys. Still recommend this?

The Naim UnitiQute is an integrated amp with IC Chip volume control. Right now I only use Sys as switch box.
Yes, try going Gungnir MB > Sys > Aegir using short ~0.5M interconnects. If bass and dynamics suffer, then add an active preamp (Freya S or Freya +). Either Freya will allow for adding a second Aegir (dual Aegirs in monoblock mode) for more power if needed.

Last edited:
     Share This Post
post-15433834
Post #56,158 of 60,094

tincanear

100+ Head-Fier
Joined
Sep 2, 2019
Messages
438
Reaction score
723
Location
west coast, USA
Joined
Sep 2, 2019
Location
west coast, USA
Posts
438
Likes
723
The SYS is totally passive. If the SYS volume control is at about 10 o'cloock or greater, you should not experience any sound quality loss, since Gumby has a low [75 ohm] output impedance.
Actually, I believe with the 75 ohm output impedance of the Gungnir MB, the effective source impedance seen by the amp input is minimized at the extreme ends of the volume control range (and is highest in the middle third of its range, reaching a max of about 5K). The 22K input impedance of the Aegir will result in a loss of a dB or two across the band (not an issue in this situation). The high frequency roll-off will depend on the interconnect capacitance as well as the Aegir's (unspecified) input capacitance. The Aegir is all BJT, so it doesn't have JFET inputs (which can exhibit varying input capacitance with respect to input voltage, which leads to non-linear distortion when used with passive or other high output impedance (some all tube) preamps). Unless someone has this setup and has an Audio Precision or Avermetrics handy, gonna have to try it and see how it sounds...

Last edited:
     Share This Post
post-15433857
Post #56,159 of 60,094

tincanear

100+ Head-Fier
Joined
Sep 2, 2019
Messages
438
Reaction score
723
Location
west coast, USA
Joined
Sep 2, 2019
Location
west coast, USA
Posts
438
Likes
723
anyone received their production Jotunheim R yet? I thought at least someone local to Schiit would have picked one up at the SchiitR the day it was announced...

aside, time to locate and break out some Kitaro CD's...

Last edited:
     Share This Post
post-15433882
Post #56,160 of 60,094

bcowen

Headphoneus Supremus
Joined
Jan 3, 2018
Messages
4,373
Reaction score
7,285
Location
North Carolina
Joined
Jan 3, 2018
Location
North Carolina
Posts
4,373
Likes
7,285
Martin-Logan CLS, oooh, I've always wanted a pair. My college graduation present to myself (after a couple of years' savings) was either Apogee or Martin-Logan: Apogee won.

I'm not a big fan of redoing other people's work. Leave Star Trek alone. Don't colorize classic movies. And, please Hollywood, no more remakes. Somebody, somewhere, has to be writing original stories that are worth bringing to the screen.

I hope Tammy Wynette doesn't suffer the same fate as Frank. The lyric just wouldn't work in reverse.
A pair of Apogee Divas driven by some beastly amps is what started this lifelong addiction for me. I listened to them in a store, became infected, couldn't possibly afford them, and left. Went back 2 days later, listened again, still couldn't afford them and left. On my third trip I left with a pair of Duettas. Couldn't afford those either, but they were less unaffordable than the Divas. The rabbit hole appeared when I got home and found my 40wpc Harman Kardon receiver wouldn't play them very loud... :relaxed:
