Niimbus Ultimate Series US4/US4+/US5/US5 Pro Headphone Amps - by Lake People
Mar 31, 2018 at 9:28 AM Thread Starter Post #1 of 595

Fegefeuer

Headphoneus Supremus
Joined
Mar 17, 2011
Posts
2,922
Likes
1,585
Update February 26th 2021:

US5 and US5 Pro will be released with pentaconn/4.4mm output. Both are the same amps (US4+) now except being different on the volume control.


Review by Project86: https://www.head-fi.org/threads/rev...r-includes-large-high-end-amp-roundup.886668/


this is all early info I gathered, can't go into a lot of details because I don't know them yet. All the weeks until the Munich High End Show will reveal more details and info about these amps until we'll get the full picture. I'll keep this thread updated




US4+ and US4 are flagship headphones amps, and to each other basically aequivalent as the Violectric V281 is to the V280. If you know both you know what to expect in terms of what they offer in features, however in performance and quality these amps will take everything to another level, thus they will leave the violectric sphere and go under the name "Niimbus".



US4+ front



US4+ back



US4 front


US4 back


Internals: white PCB defines the US amps and upcoming DACs










US4 Volume Control


US4 Power LED


US4+ front and back shots








US4+:

-one version/edition, no options, every US4+ will have the same features and performance
-remote included
-one 4-PIN XLR Headphone Out and 2x6,3mm, open to a Pentaconn connection but not likely
-NO Digi Inputs anymore Instead you will find 1xXLR, 2xRCA inputs (1 on the US4) and 1xXLR/1xRCA output
-reed relais volume control, 256 steps@0,4db (bonus: less noise than the V281's relais option)
-Balance control is back (remember V281)
-protection features: delayed power-on, instant cutoff, DC protection, Overload protection, Temperature monitoring and safe shutdown
-pregain in 7 steps: -15db, -12db, -6db, 0db, +6, +12, +18 dB
-about 12db less noise than the V281 under maximum stability ((balanced)
-30V@600 Ohm
-2x25W Tor. Transformers, 52.800 uF filtering capacity through Nichikon caps
-coupling capacitors will be polypropylen caps only

The US4 has everything the US4+ has, except the following features:

-relais based volume control
-remote
-front panel buttons for switching inputs (inputs can be selected on the back)
-balance control

dimensions: 350mmx280mmx80mm (width, depth, height)



shipping will probably start early September 2018.

prices will be 5000€ inc. VAT for the US4+ and 4000€ for the US4


Attachments

  • US_4_software-en.pdf
    391.2 KB · Views: 0
Last edited:
Mar 31, 2018 at 2:20 PM Post #5 of 595

musicmaker

1000+ Head-Fier
Joined
Jan 2, 2004
Posts
1,457
Likes
145
Happy April fools !

Apr 1, 2018 at 5:49 AM Post #6 of 595

Fegefeuer

Headphoneus Supremus
Joined
Mar 17, 2011
Posts
2,922
Likes
1,585
@Fegefeuer, do you know width and depth of the amps?
I mean, is it possible to stack them with Violectric/Lake People gear?

350mm width, about 280mm depth and with feet 80mm high. I'm sure you'll be able to stack your DAC and your Femto onto them but the looks and material are completely different. There will be no match.

Last edited:
Apr 3, 2018 at 6:44 AM Post #10 of 595

roskodan

Headphoneus Supremus
Joined
Jan 1, 2013
Posts
2,083
Likes
1,352
Location
EU
i thought it was an April fools joke, but then i got an email from lake people confirming this XD, so now i'm wondering, did they confirm the joke or that it's legit :9 ?!?!?!?!?!?!?!?! :k701smile:

Apr 3, 2018 at 11:09 AM Post #13 of 595

fdg

Member of the Trade: Lake People
Joined
Oct 29, 2009
Posts
175
Likes
154
Is it possible to buy this unit at the Munich show?
We will show ready working prototypes from Niimbus US 4 and US 4+ during the HiEnd show in Munich.
There will be only few things to be altered until we begin the production.
We plan to be ready for sale from Spetember / Oktober 2018.
Pre-Orders welcome - of course without a prepayment.
There will be 2 DACs to follow the headphone amps early 2019, one of them also with analog inputs.
Afterwards we plan to release some other analog items including a power amp.

Apr 5, 2018 at 9:56 AM Post #14 of 595

roskodan

Headphoneus Supremus
Joined
Jan 1, 2013
Posts
2,083
Likes
1,352
Location
EU
I'm really interested to see if they stayed within the Violectric sound signature, or went for something substantially different. "Niimbus" stands for 'dark cloud' i guess, interesting naming choice. The height i suppose was meant to be 80mm not 8mm :9

Apr 5, 2018 at 11:27 AM Post #15 of 595

fdg

Member of the Trade: Lake People
Joined
Oct 29, 2009
Posts
175
Likes
154
One aspect for "Niimbus" is meteorological and means a special kind of cloud.
We had a more general approach in mind as "Niimbus" means -> reputation and brilliance,
also there is a theological aspect as "Niimbus" also stands for -> halo.
But "Nimbus" in our case is not intended to describe the sound signature !
Also, there is no "Niimbus" in the real world with double ii.
So, everybody is invited to pick the meaning he prefers :smile_phones:
