mod: Monoporice 8323
post-8391038
Thread Starter
Post #1 of 208

Armaegis

Modern Modder Man of Manitoba
HTML... uphill, both ways!
Joined
Oct 18, 2009
Messages
12,225
Reaction score
1,155
Joined
Oct 18, 2009
Posts
12,225
Likes
1,155
Plenty of talk of this little $30 wonder here... http://www.head-fi.org/t/569239/monoprice-hi-fi-dj-style-headphone-review

Generally considered a great value, particularly if you're looking for something bass heavy.

Here's my little mod experiment. This is a fairly standard treatment (with variations) that I give most headphones when I'm in the mood to crack them open...


1. Sprayed the cups with a rubber sealant. Sprayed the rear of the driver baffle as well (after masking all the important bits). This is to provide a seal and slightly mitigate those hard plastic reflective surfaces. Do note that this step is very messy. If you were to skip any step, this would be it.



2&3. Place acoustic foam into the cups. The type I used had a heavy rubber backing.





4. Double layer of micropore tape over the cup vents. Scrap piece of acoustic foam wedged into the hinge knob, since the hinge actually has a hole that vents directly out and is arguably larger than the cup vent itself.




5. Vibration dampener (dynamat or fatmat or other) on rear of driver. I just used scrap pieces of whatever I had left. I modded a previous pair that simply had a square rotated 45° on the back. Micropore tape over half the driver vents.



6. A piece of velour and cotton layered into the cups. I teased out the cotton first, and tried to arrange them such that the wire did not lay directly against the driver but had the cotton sandwiched in between.




7. (no pic) Cut a large piece of soft thin felt the same size as the baffle plate and stuck it under the pad


Most noticeable sound changes
- better isolation
- bass maybe ever so slightly decreased, but clarity improved
- treble extension greatly improved
- midrance clarity much better (probably due to the treble)
- overall frequency response is bass sloped, with the typical treble wobbles though more subdued than other closed cans

post-8391071
Post #2 of 208

swbf2cheater

Headphoneus Supremus
Joined
Aug 14, 2009
Messages
5,045
Reaction score
121
Joined
Aug 14, 2009
Posts
5,045
Likes
121
This is the single greatest thing I have ever seen.   God bless you, sir.  <3



     Share This Post
post-8391535
Post #3 of 208

nick n

Headphoneus Supremus
Joined
Feb 3, 2011
Messages
5,265
Reaction score
1,228
Joined
Feb 3, 2011
Posts
5,265
Likes
1,228
what exact effect does the micropore taping have? I have a few cans with those baffle equalizing vents..  And do you have an exact brand for the spray rubber?

     Share This Post
post-8391580
Post #4 of 208

hartlocker

New Head-Fier
Joined
May 11, 2012
Messages
25
Reaction score
10
Joined
May 11, 2012
Posts
25
Likes
10
Wow! Thank you SO much for taking my request! I didn't think you would do it, but you did! This community just keeps on surprising me!

Edit: Haha, also noticed you live in the same city as me! Cheers!

     Share This Post
post-8391719
Post #5 of 208

Armaegis

Modern Modder Man of Manitoba
HTML... uphill, both ways!
Joined
Oct 18, 2009
Messages
12,225
Reaction score
1,155
Joined
Oct 18, 2009
Posts
12,225
Likes
1,155
Quote:
what exact effect does the micropore taping have? I have a few cans with those baffle equalizing vents..  And do you have an exact brand for the spray rubber?

From Canadian Tire: http://www.canadiantire.ca/AST/browse/3/HouseHome/1/HeatingAirConditioning/WeatherStripping/PRD~0641101P/BK+Roof+Repair+Spray.jsp?locale=en

All the micropore tape stuff made very minor differences, and I wouldn't discount any of it to placebo.  Using solid tape usually has more perceptible differences. That said, here are my thoughts...
- Taping over the cup vents I find generally improves isolation a tiny tiny bit and gives a bit more "thump" in the midbass
- Taping over the holes on the magnet plate decreased bass
- Taping over some of the driver vents seemed to improve clarity in the bass without sacrificing quantity (from experimenting with grados, popping them open improves bass quantity but it becomes boomier and less controlled)

     Share This Post
post-8400048
Post #6 of 208

Armaegis

Modern Modder Man of Manitoba
HTML... uphill, both ways!
Joined
Oct 18, 2009
Messages
12,225
Reaction score
1,155
Joined
Oct 18, 2009
Posts
12,225
Likes
1,155
Added step 7. Cut a large piece of soft thin felt and stuck it under the pad. Gives a bit more body to the bass.

     Share This Post
post-8403099
Post #7 of 208

hartlocker

New Head-Fier
Joined
May 11, 2012
Messages
25
Reaction score
10
Joined
May 11, 2012
Posts
25
Likes
10
Hey, these just came in today, and I'm loving them! My first pair of decent 'phones! They sound great! I came here to ask about your opinion on burning these in, do they get better or does not much change? Thanks!


     Share This Post
post-8403172
Post #8 of 208

Armaegis

Modern Modder Man of Manitoba
HTML... uphill, both ways!
Joined
Oct 18, 2009
Messages
12,225
Reaction score
1,155
Joined
Oct 18, 2009
Posts
12,225
Likes
1,155
I am not a believer in driver burn-in beyond the first few minutes or so loosening things up. What makes a far bigger difference is the pads, which as they break-in will soften and (usually) provide a better seal as well as bringing the drivers closer to your ear, which *does* greatly affect the sound.

Let me know if you ever decide to open them up and experiment.

     Share This Post
post-8403282
Post #9 of 208

hartlocker

New Head-Fier
Joined
May 11, 2012
Messages
25
Reaction score
10
Joined
May 11, 2012
Posts
25
Likes
10
Do you open them up by just taking off the pads, then under the felt there's screws?

Edit: Not going to do it now, just for future reference.

     Share This Post
post-8403313
Post #10 of 208

Armaegis

Modern Modder Man of Manitoba
HTML... uphill, both ways!
Joined
Oct 18, 2009
Messages
12,225
Reaction score
1,155
Joined
Oct 18, 2009
Posts
12,225
Likes
1,155
Yeah it's pretty simple to open them up. Don't even have to go through felt. You might have to poke through paper, I don't remember, but it's nothing that can possibly affect sound.

     Share This Post
post-8403459
Post #11 of 208

DaBomb77766

Headphoneus Supremus
Joined
Apr 14, 2011
Messages
3,068
Reaction score
70
Joined
Apr 14, 2011
Posts
3,068
Likes
70
Huh, are those HD-25 cups sitting over there in the first picture? :p

     Share This Post
post-8403477
Post #12 of 208

Armaegis

Modern Modder Man of Manitoba
HTML... uphill, both ways!
Joined
Oct 18, 2009
Messages
12,225
Reaction score
1,155
Joined
Oct 18, 2009
Posts
12,225
Likes
1,155
Yes they are. I sprayed them with the rubber coating at the same time as the 8323. I've given the HD25 a similar modding treatment


     Share This Post
post-8403861
Post #14 of 208

Armaegis

Modern Modder Man of Manitoba
HTML... uphill, both ways!
Joined
Oct 18, 2009
Messages
12,225
Reaction score
1,155
Joined
Oct 18, 2009
Posts
12,225
Likes
1,155
Pretty good actually. It maintains everything I like about them, brings the bottom end up just a little bit more, better isolation, and tames those treble peaks so they aren't quite so piercing at times.

     Share This Post
post-8407774
Post #15 of 208

hans030390

1000+ Head-Fier
Joined
Dec 4, 2008
Messages
1,372
Reaction score
607
Joined
Dec 4, 2008
Posts
1,372
Likes
607
Weird. I thought I had posted here earlier. Guess I didn't!

Either way, I'm a sucker for budget cans, so I placed an order on these yesterday. I'll be using some leftover modding material from my T50RP.

     Share This Post
