Magni 3 Impressions
post-13732211
Thread Starter
Post #1 of 2,548

CarlosUnchained

100+ Head-Fier
Joined
Oct 6, 2016
Messages
484
Reaction score
127
Location
The Black Lodge
Joined
Oct 6, 2016
Location
The Black Lodge
Posts
484
Likes
127




Frequency Response: 20Hz-20Khz, -0.1db, 2Hz-900KHz, -3dB

Maximum Power, 16 ohms: 3W RMS per channel
Maximum Power, 32 ohms: 2W RMS per channel
Maximum Power, 50 ohms: 1.3W RMS per channel
Maximum Power, 300 ohms: 430mW RMS per channel
Maximum Power, 600 ohms: 230mW RMS per channel

THD: Less than 0.001%, 20Hz-20KHz, at 1V RMS, less than 0.02% at 5V RMS into 32 ohms
IMD: Less than 0.001%, CCIF

SNR: Greater than 108db, unweighted, referenced to 1V RMS

Crosstalk: -70dB, 20 Hz-20KHz

Output Impedance: Less than 0.3 ohms at either gain

Gain: 2 (6db) or 7 (17db), selectable via rear switch
Topology: fully discrete, fully complementary all-bipolar, symmetrical current-feedback design with no capacitors in the signal path and DC servo
Protection: Standard failsafe DC power input and muting relay

Power Supply: “Wall wart” style 24VA 14VAC transformer, regulated +/- 17V rails with over 6,000uF filter capacitance
Power Consumption: 6W

Size: 5 x 3.5 x 1.25”

Weight: 1 lb

post-13732263
Post #3 of 2,548

MementoMori99

100+ Head-Fier
Joined
Mar 31, 2017
Messages
210
Reaction score
58
Location
Southern California
Joined
Mar 31, 2017
Location
Southern California
Posts
210
Likes
58
It is my opinion that for relatively smooth treble, the Vali 2, Asgard 2 and Lyr 2 are the best options for Schiit amps. I own the Vali 2 because it suits my needs(power and preference for smooth treble) and has a price point of under $200. I am curious as to whether the Magni 3 has smooth treble.

Last edited:
     Share This Post
  • Like
Reactions: ToddRaymond
post-13732295
Post #4 of 2,548

HipHopScribe

Headphoneus Supremus
Joined
Mar 9, 2008
Messages
1,623
Reaction score
416
Joined
Mar 9, 2008
Posts
1,623
Likes
416
Anybody with a Vali 2 ordering a Magni 3?

I'd love to hear some comparisons before purchasing.
I have a Vali 2, just ordered a Magni 3. I'm curious to see how they compare

post-13732553
Post #6 of 2,548

neurofone

100+ Head-Fier
Joined
Sep 18, 2012
Messages
116
Reaction score
17
Joined
Sep 18, 2012
Posts
116
Likes
17
I have a Modi 2 / Vali 1 combo and just ordered the Magni 3. Got a pair of AKG K7XX. As much as I like the Vali, I can't stand the microphonics every time I touch the volume knob. Back to solid state !

     Share This Post
post-13732554
Post #7 of 2,548

lordskh

Head-Fier
Joined
Jul 20, 2017
Messages
63
Reaction score
7
Location
Baltimore, MD
Joined
Jul 20, 2017
Location
Baltimore, MD
Posts
63
Likes
7
I'm interested to see how this will compare with the Asgard 2 given that the Magni 3 stemmed from the development of the Asgard 3 and is less than half the price.

     Share This Post
post-13732658
Post #8 of 2,548

genclaymore

Headphoneus Supremus
Joined
Jun 3, 2007
Messages
2,158
Reaction score
128
Joined
Jun 3, 2007
Posts
2,158
Likes
128
Age
37
I really curious on how it compares to the jotunheim's SE connection. Since it looks like the magni 3 packs alot of power for its small size.

post-13732729
Post #10 of 2,548

Matt*S.

New Head-Fier
Joined
Aug 30, 2007
Messages
22
Reaction score
12
Joined
Aug 30, 2007
Posts
22
Likes
12
Ordered a Magni 3, currently using a Maverick D2 DAC, we'll see how it sounds soon. I'll be comparing it with a Meier Corda Aria as well as a LD MKIII.

     Share This Post
post-13732730
Post #11 of 2,548

ToddRaymond

Previously known as Turdski
Joined
Sep 20, 2014
Messages
385
Reaction score
139
Location
Creston, BC
Joined
Sep 20, 2014
Location
Creston, BC
Posts
385
Likes
139
I think I'm gonna try one downstream from my Saga, a la 'Sagaheim'. Previously I had a Vali 2 (among many other Schiit amps), but had to sell off a bunch of stuff. I'm curious how Saga > Magni 3 will compare to the Vali 2, which I found to very enjoyable.

     Share This Post
post-13732815
Post #12 of 2,548

CarlosUnchained

100+ Head-Fier
Joined
Oct 6, 2016
Messages
484
Reaction score
127
Location
The Black Lodge
Joined
Oct 6, 2016
Location
The Black Lodge
Posts
484
Likes
127
I really curious on how it compares to the jotunheim's SE connection. Since it looks like the magni 3 packs alot of power for its small size.
Magni 3 can do balanced. Just buy two and a splitter. Still $200 cheaper than the Jot and nothing less than 6W RMS @ 16 Ohms.

     Share This Post
  • Like
Reactions: alphanumerix1
post-13733106
Post #13 of 2,548

TjPhysicist

100+ Head-Fier
Joined
Dec 4, 2012
Messages
362
Reaction score
74
Location
Toronto, Ontario, Canada
Joined
Dec 4, 2012
Location
Toronto, Ontario, Canada
Posts
362
Likes
74
ok guys question: i can swap my M2 for an M3 (I use mrspeakers Aeon so don't REALLY need the extra power). BUT the switch will cost me $50-$70....should i do it?

     Share This Post
post-13733107
Post #14 of 2,548

TjPhysicist

100+ Head-Fier
Joined
Dec 4, 2012
Messages
362
Reaction score
74
Location
Toronto, Ontario, Canada
Joined
Dec 4, 2012
Location
Toronto, Ontario, Canada
Posts
362
Likes
74
Magni 3 can do balanced. Just buy two and a splitter. Still $200 cheaper than the Jot and nothing less than 6W RMS @ 16 Ohms.
is that really how that works? i just hook up w magni's to my modi via a splitter and now i have a balanced mega-magni?

     Share This Post
post-13733201
Post #15 of 2,548

Pyrolistical

New Head-Fier
Joined
Jan 23, 2017
Messages
49
Reaction score
26
Joined
Jan 23, 2017
Posts
49
Likes
26
Magni 3 can do balanced. Just buy two and a splitter. Still $200 cheaper than the Jot and nothing less than 6W RMS @ 16 Ohms.
How do you convert the two 3 pole 1/4" to a single 4 pin xlr?

You would need to pin out the XLR male jack with:
pin 1: left T+R
pin 2: left S
pin 3: right T+R
pin 4: right S

Dunno where you would buy such a cable...

Schiit should do an Aprils fools joke that puts two Vidars in monoblock into a single larger chassis and adds the specs together

Last edited:
     Share This Post
